PMO carbs Installation Pictures thread

Hi everyone!
Just opened up a brand new box of PMO carbs for my 83 911 SC.
I'm hoping to get a thread going where people post close up pictures of their PMO install, the linkages, fuel line routing, breather hose connections, orientation of the carbs themselves and the manifolds, etc....

I'll post some when I get to that point, but I'm hoping people have some pics to look at during this install. No offense to PMO but their documentation doesn't have a lot of pictures in it. I work better from a visual.
Old 01-27-2015, 05:41 PM
  Pelican Parts Technical Article Directory    Reply With Quote #1 (permalink)
Registered User

universeman's Avatar

Join Date: Oct 2014
Location: Lone Star State
Posts: 1,096
Garage
I just want to say: Woah. Sweet. Can't wait for this thread. (subscribing)

Go hdrockerroller go!
__________________
Jason - Austin, TX
82 911 SC targa
Old 01-27-2015, 05:59 PM
  Pelican Parts Technical Article Directory    Reply With Quote #2 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Looks like there some good pictures here:

PMO 46mm Carburetor Installation on 3.2L
Old 01-27-2015, 06:24 PM
  Pelican Parts Technical Article Directory    Reply With Quote #3 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
A thread on the fuel lines.
AN-6 Fuel Line Plan for CIS to PMO Carb Conversion
Old 01-27-2015, 06:42 PM
  Pelican Parts Technical Article Directory    Reply With Quote #4 (permalink)
Registered User

Gordo2's Avatar

Join Date: Sep 2002
Location: Stafford, VA
Posts: 1,585
Carb Tuning

And a few more with guts exposed:
Gordo's PMO Carb Tuning

Good luck, fun project.

Gordo
__________________
Don Gordon "Gordo"
'83 911SC Targa
'87 FJ-60 TLC
Old 01-27-2015, 07:15 PM
  Pelican Parts Technical Article Directory    Reply With Quote #5 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Possible Throttle Linkage issues
PMO install and throttle linkage
Old 01-27-2015, 07:17 PM
  Pelican Parts Technical Article Directory    Reply With Quote #6 (permalink)
Registered User

Gordo2's Avatar

Join Date: Sep 2002
Location: Stafford, VA
Posts: 1,585
Covered in Carb Tuning Thread

Check the previous link to the Carb Tuning thread - I addressed the throttle linkage issue there.

Gordo
__________________
Don Gordon "Gordo"
'83 911SC Targa
'87 FJ-60 TLC
Old 01-27-2015, 07:25 PM
  Pelican Parts Technical Article Directory    Reply With Quote #7 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
PMOs installation and setup guide.
PMO Porsche 911 Carburetion - Installation
Old 01-27-2015, 07:25 PM
  Pelican Parts Technical Article Directory    Reply With Quote #8 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Gordo2: I'm installing on an 83 911 SC, but I'm installing the short manifolds. Do you think I'll need to update the linkage?
Old 01-27-2015, 07:27 PM
  Pelican Parts Technical Article Directory    Reply With Quote #9 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Info on pressure regulator issues.
PMO Reg Won't Go Lower Than 5 PSI
Old 01-27-2015, 07:49 PM
  Pelican Parts Technical Article Directory    Reply With Quote #10 (permalink)
Registered speed offender

78SCRSMAN's Avatar

Join Date: Sep 2009
Location: Spokane, WA
Posts: 1,112
Garage
I'm curious as to what approach folks are using in regards to the power brake. I've seen photos of where the threaded port is on the intake manifold but so far I can't find anything showing hoses and such... What type of fitting, whether to use a check valve, hose routing, etc. The brake booster has a check valve but am wondering if people are installing an additional one in the engine compartment.

I haven't reached the "buy the carbs" point yet but am placing orders for -an fuel lines and will be using -an type hoses for vacuum and crankcase so am trying to figure out what to buy.

Thanks in advance for any help/photos that can be posted here.
__________________
If you keep looking back, you'll never move forward.
http://forums.pelicanparts.com/paint-bodywork-discussion-forum/506621-project-911r-something.html
Old 01-28-2015, 07:29 AM
  Pelican Parts Technical Article Directory    Reply With Quote #11 (permalink)
Straight shooter

Lapkritis's Avatar

Join Date: Sep 2012
Location: Vilnius
Posts: 3,050
Garage
Power brakes? Eat your wheaties.
__________________
“Of the value traps, the most widespread and pernicious is value rigidity. This is an inability to revalue what one sees because of commitment to previous values. In motorcycle maintenance, you MUST rediscover what you do as you go. Rigid values makes this impossible.”
― Robert M. Pirsig, Zen and the Art of Motorcycle Maintenance: An Inquiry Into Values
Old 01-28-2015, 07:44 AM
  Pelican Parts Technical Article Directory    Reply With Quote #12 (permalink)

Now Available for Ordering:   101 Projects For Your BMW 3 Series 1982-2000  [more info]
Straight shooter

Lapkritis's Avatar

Join Date: Sep 2012
Location: Vilnius
Posts: 3,050
Garage




__________________
“Of the value traps, the most widespread and pernicious is value rigidity. This is an inability to revalue what one sees because of commitment to previous values. In motorcycle maintenance, you MUST rediscover what you do as you go. Rigid values makes this impossible.”
― Robert M. Pirsig, Zen and the Art of Motorcycle Maintenance: An Inquiry Into Values
Old 01-28-2015, 07:56 AM
  Pelican Parts Technical Article Directory    Reply With Quote #13 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Power brakes connections.

If you order your PMOs for power brakes the left manifold will have a boss drilled into it to accept the included check valve nipple connector that connects directly to your power brake booster vacuum line. I'll post pictures when I get a chance.
Old 01-28-2015, 12:53 PM
  Pelican Parts Technical Article Directory    Reply With Quote #14 (permalink)
83 911 Production Cab #10

JJ 911SC's Avatar

Join Date: Jun 2009
Location: Ottawa, Ontario, Canada
Posts: 10,244
Garage
Quote:
Originally Posted by 78SCRSMAN View Post
I'm curious as to what approach folks are using in regards to the power brake. I've seen photos of where the threaded port is on the intake manifold but so far I can't find anything showing hoses and such...
Quote:
Originally Posted by hdrockerroller View Post
If you order your PMOs for power brakes the left manifold will have a boss drilled into it to accept the included check valve nipple connector that connects directly to your power brake booster vacuum line. I'll post pictures when I get a chance.
78SCRSMAN

As per hdrockerroller mentioned, It came with a brass fitting that would fit in the power assist vacuum line (still needs the check valve). Its as simple of repluging the hose that was removed. In my case, I put a T fitting so that I could run a smaller hose to the fuel pressure regulator.

__________________
Who Will Live... Will See

83 911 Production Cab #10, Slightly Modified: Slanted, 3.2, PMO EFI, TECgt, CE 911 CAM Sync / Pulley / Wires, SSI, Dansk Sport 2/2, 17" Euromeister, CKO GT3 Seats, Going SOK Super Charger
Old 01-28-2015, 02:33 PM
  Pelican Parts Technical Article Directory    Reply With Quote #15 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Can someone post pics of the throttle linkage connections coming from car to PMOs. Do you still use the stock throttle linkage plate that attaches to theblock?
Old 01-28-2015, 03:32 PM
  Pelican Parts Technical Article Directory    Reply With Quote #16 (permalink)
Registered User

Join Date: Dec 2012
Location: Seattle
Posts: 2,495
Quote:
Originally Posted by 78SCRSMAN View Post
I'm curious as to what approach folks are using in regards to the power brake. I've seen photos of where the threaded port is on the intake manifold but so far I can't find anything showing hoses and such... What type of fitting, whether to use a check valve, hose routing, etc. The brake booster has a check valve but am wondering if people are installing an additional one in the engine compartment.

I haven't reached the "buy the carbs" point yet but am placing orders for -an fuel lines and will be using -an type hoses for vacuum and crankcase so am trying to figure out what to buy.

Thanks in advance for any help/photos that can be posted here.
I have older PMO manifolds with no vacuum port. I picked up an electric vacuum pump from Metric Mind, not the cheapest solution but others on the forum have used it quite successfully. It's Swiss made and supposedly the quietest pump you can get.

MES 70/6E | Metric Mind Corporation
__________________
1982 911 Targa, 3.0L ROW with Webers
Old 01-28-2015, 03:41 PM
  Pelican Parts Technical Article Directory    Reply With Quote #17 (permalink)
83 911 Production Cab #10

JJ 911SC's Avatar

Join Date: Jun 2009
Location: Ottawa, Ontario, Canada
Posts: 10,244
Garage
Quote:
Originally Posted by Ayles View Post
I have older PMO manifolds with no vacuum port. I picked up an electric vacuum pump from Metric Mind, not the cheapest solution but others on the forum have used it quite successfully. It's Swiss made and supposedly the quietest pump you can get.

MES 70/6E | Metric Mind Corporation
Even if you don't order or buy one without the port tap and fitted with the brass adapter, the 'new' PMO has the boss there that one can tap.
__________________
Who Will Live... Will See

83 911 Production Cab #10, Slightly Modified: Slanted, 3.2, PMO EFI, TECgt, CE 911 CAM Sync / Pulley / Wires, SSI, Dansk Sport 2/2, 17" Euromeister, CKO GT3 Seats, Going SOK Super Charger
Old 01-28-2015, 04:02 PM
  Pelican Parts Technical Article Directory    Reply With Quote #18 (permalink)
83 911 Production Cab #10

JJ 911SC's Avatar

Join Date: Jun 2009
Location: Ottawa, Ontario, Canada
Posts: 10,244
Garage
Quote:
Originally Posted by hdrockerroller View Post
Can someone post pics of the throttle linkage connections coming from car to PMOs. Do you still use the stock throttle linkage plate that attaches to theblock?
No you don't. The linkage goes from a shaft located at #3 intake (inboard).

For a reference point, if you look at the left half of the picture you will see 2 of the 3 studs cover with red heat shrink where the old linkage was attached to the block.

__________________
Who Will Live... Will See

83 911 Production Cab #10, Slightly Modified: Slanted, 3.2, PMO EFI, TECgt, CE 911 CAM Sync / Pulley / Wires, SSI, Dansk Sport 2/2, 17" Euromeister, CKO GT3 Seats, Going SOK Super Charger
Old 01-28-2015, 04:11 PM
  Pelican Parts Technical Article Directory    Reply With Quote #19 (permalink)
Registered User

Join Date: Oct 2010
Posts: 124
Garage
Excellent picture, exactly what I was looking for.
So the PMOs connect directly to the linkage rod that comes through the tin.
Old 01-28-2015, 04:22 PM
